Home Stretch | Making blind people see again with a wireless implant

Being able to see without eyes. It sounds like a miracle, but in the not-too-distant future a new brain chip needs to allow the blind and visually impaired to perceive images again. PhD student Adedayo Omisakin worked on wireless communication from and to this innovative implant. He will defend his research at the department of Electrical Engineering on Friday, April 22nd.

by
photo Rien Boonstoppel

None other that blind singer Stevie Wonder expressed his enthusiasm last week for the smart glasses developed by TU Delft startup Envision. These glasses are equipped with a built-in camera and offer users greater independence by reading texts or locating objects. But in order to allow the blind and visually impaired to actually see images again – admittedly made up of pixels – the camera in the glasses needs to be linked to an implant. That is the objective of Dutch research program NESTOR, a consortium with scientists from various institutes, including the Netherlands Institute for Neuroscience, the University of Twente, Radboud University, Maastricht University and TU/e.

Briefly explained: the camera images of the glasses that the blind person is wearing are processed in a mini computer and subsequently transmitted wirelessly to a brain chip. That chip consists of multiple electrodes that stimulate cells in the visual cortex with electric currents, Adedayo Omisakin explains. Within the NESTOR project, PhD student Tom van Nunen, project leader Mark Bentum and Omisakin work on the wireless communication part. Van Nunen, who will defend his thesis later this year, worked on the wireless power supply of the implant, whereas Omisakin focused on wireless communication from and to the implant.

Damaged nerves

“Many blind people have damaged nerves between the eyes and the brain, which is why our only option is to directly stimulate the visual cortex. For that, you need an external camera, image processing and implanted electrodes. Preferably without wires, because this not only prevents infections in the brain area from occurring, but also makes patients much more mobile.” Omisakin talked to several neurologists and neurosurgeons and was allowed to visit the American manufacturer of the electrodes. “The electrodes are grouped into 16 tiles, with 64 active electrodes each. That’s a staggeringly high total of 1024 electrodes. We decided to place the central transceiver, which communicates with the tiles, just below the skin. This way, we won’t have any unnecessary signal loss induced by the skull.”

Over a period of four years, Omisakin turned into a super engineer, he says with a smile. “I did everything from conceptualization to validation. First, I compared various potential communication techniques and delved into many details: data rates, power consumption, frequency bands. Next came the lab work. A lot of lab work. But we soon managed to achieve a promising data rate in our demonstration model. And we even got to a consumption of less than 1 mW in an integrated circuit with the use of special semiconductor technology.”

Epilepsy

That’s good news, because previous implants consumed a lot of power, which potentially leads to epileptic seizures in patients. Jens Naumann was one of those patients. The Canadian was one of the first blind persons who was able to (briefly) see again thanks to a brain implant. However, the severe epileptic seizures and the many infections to the wires protruding from his head eventually forced the partial removal of the implant. Omisakin met with Naumann during one of the NESTOR meetings and was impressed by his enthusiasm for Omisakin’s research. This only inspired the PhD student even more to successfully develop wireless communication technology for brain chips. “Researchers from the Netherlands Institute for Neuroscience already tested the new brain chips with 1024 electrodes in monkeys, and they were able to perceive characters, moving objects and lines. Our system too is ready for testing, after a few adjustments. The number of electrodes eventually needs to increase further if we want to have images of a usable quality. We are making serious progress, but we aren’t there yet. Still, I believe that we will be able to make a difference for the blind and visually impaired with this technology within the next five to ten years.”

A new PhD student has already picked up where Omisakin left off. They email each other now and then, so that Omisakin remains indirectly involved, even though he recently started working for chip manufacturer NXP Semiconductors. Because after his move from Nigeria to Cyprus, where he studied, he decided to remain in Eindhoven, which he considers “the place to be when it comes to cutting edge technology.” Unfortunately, his family from Nigeria won’t be able to attend his final academic activity and will be forced to follow his PhD ceremony online. Let’s hope that wireless technology will be of some assistance here too.
